switch# test cable-diagnostics 52
This command will cause a loss of link on all tested ports and will take
several seconds per port to complete. Use the 'show cable-diagnostics'
command to view the results.
Continue (y/n)? Y
switch# show cable-diagnostics 52
Cable Diagnostic Status - Transceiver Ports
MDI Cable Distance Pair Pair MDI
Port Pair Status to Fault Skew Polarity Mode
---- ------ --------- -------- ----- ------- -----
52 1-2 OK 0 m 0 ns Normal MDI
3-6 OK 0 m 0 ns Normal
4-5 OK 0 m 0 ns Normal MDIX
7-8 OK 0 m 0 ns Normal
Faulty cable test
switch# test cable-diagnostics 51
This command will cause a loss of link on all tested ports and will take
several seconds per port to complete. Use the 'show cable-diagnostics'
command to view the results.
Continue (y/n)? y
switch# show cable-diagnostics 51
Cable Diagnostic Status - Transceiver Ports
MDI Cable Distance Pair Pair MDI
Port Pair Status to Fault Skew Polarity Mode
---- ------ ----------- ---------- ------ ---------- ------
51 1-2 OK 0 m 0 ns
3-6 Short 1 m 0 ns
4-5 Short 1 m 0 ns
7-8 OK 0 m 0 ns
switch# test cable-diagnostics 52
This command will cause a loss of link on all tested ports and will take
several seconds per port to complete. Use the 'show cable-diagnostics'
command to view the results.
Continue (y/n)? Y
switch# show cable-diagnostics 52
Cable Diagnostic Status - Transceiver Ports
MDI Cable Distance Pair Pair MDI
Port Pair Status to Fault Skew Polarity Mode
---- ------ ----------- ---------- ------ ---------- ------
52 1-2 Open 0 m 0 ns
3-6 Open 0 m 0 ns
Chapter 19 Cable Diagnostics 645
