7. Simple Operation Procedure
89
79
Select the F1 (Edit) key on the Mode Selection
screen.
Select the F2 (Prog) key on the Edit mode screen.
Select the F1 (Mdfy) key on the Edit-Prog (program
edit and new creation) screen.
The screen changes to the program No. input mode
screen. The cursor is located at the program No.
Press the return key to move the cursor to the
location of the step No.
* When the program’s data is already input,
overwrite it (the original data is lost) or select the
program No. with no data input. The program No. or
step No. over which the cursor is located can be
changed with the PAGE UP and PAGE DOWN keys.
In addition, pressing the return key after inputting a
numerical value with the 10 key can change the
program No. or step No.
Also, you can change the program No. by pressing
the return key after the 10 key input. If the return key
is pressed, the cursor will move to the step No.
Then, the program No. can be changed with the
PAGE UP・PAGE DOWN keys.
You can also input it directly by using the 10 keys.
Program No.
Step No.
The number of steps saved in the
controller at the specific program.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
