IAI SEL User Manual

172
11. Program Edit
(Excluding the positioner mode of the SSEL, ASEL and PSEL controller.)
172
157
13.6. Flash ROM Writing
The edit data will be cleared by restoring the power and executing software reset, only if the
program edit data was transmitted to the controller.
To save the data after restoring the power and executing software reset, write the data to Flash
ROM.
From the final editing screen, return to the Flash ROM writing screen with the ESC key.
To write the data to Flash ROM, press the F1 (Yes)
key.
If not, press the F2 (No) key.
During Flash ROM writing, “Please Wait....” blinks.
* Never shut off the power to the controller
during Flash ROM writing.
Flash ROM writing is complete.
Return to the edit mode screen with the ESC key.
11.6.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
