IAI SEL User Manual

108
9. Execute or stop the positioner mode of the SSEL, ASEL and PSEL controller.
98
11. Execute or stop the positioner mode of the SSEL, ASEL
and PSEL controller.
When the SSEL, ASEL or PSEL controller is in the positioner mode, execute or stop the
positioner mode.
Press the F2 (Play) key from the mode selection
screen and move to the play mode screen.
There are 3 kinds of items at the play mode screen:
F1 (Run): Execute the positioner mode which is
currently specified.
F3 (Stop): Stop the positioner mode.
Note: When the SSEL, ASEL or PSEL controller is executing in the positioner mode, parameter
changes or Flash ROM writing cannot be performed.
After stopping the positioner mode by the above operation, perform parameter changes or
Flash ROM writing.
9.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
