13.2. Symbol Input during Program Edit
Symbol can be input when the cursor is located at Operand 1 · 2 (operation 1· 2), Pst (output) and
Cnd (input condition) in the “Sym” state displayed in the function key area.
Example:
Input symbol of the program step below.
Program No. 3
Symbolize position No. 10 as “TAIKIITI.”
Select the F2 (Sym) key in the function key area
within the state of the cursor that has been located in
the Operand 1 section.
Move to the symbol edit screen.
Select items to edit the symbols with function keys.
In this case, since we’re going to the edit the
Position No., select the F4 (Posi) key.
Input 10 for position No. by using the 10 keys and
press the return key.
To Next Page
