IAI SEL User Manual

16. Controller
219
202
18.3. Software Reset
Executes software reset of the controller. The data which is not written to Flash ROM will be
cleared.
Select the F2 (SRst) key on the controller item screen.
Mode Transition:
To execute a software reset, press the F1 (Yes) key.
If not, press the F2 (No) key. The screen returns to
the mode selection screen.
18.4. Error Reset
Executes error reset of the controller. Reset the message-level and action-release-level errors. If
the cause of the error is not solved, the error will reoccur again.
Select the F3 (ERst) key on the controller item screen.
Mode Transition:
To execute an error reset, press the F1 (Yes) key.
If not, press the F2 (No) key.
The screen returns to the controller item screen.
16.3.
16.4.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
