7. Simple Operation Procedure

Complete the program editing and write the data in

Flash ROM.

Press the ESC key.

(The cursor moves to the location for step No.)

Press the ESC key.

(The cursor moves to the location for program No.)

Press the ESC key.

Return to the Edit-Prog screen.

Press the ESC key.

Return to the Edit mode screen.

Press the ESC key.
