4

3. Connection to Controller

4

5

Example of Connection to X-SEL-KT/KET Type Controller

SEL-TD

(ANSI-compliant Teaching Box)

AC Power

Supply

Relay Box

Driver Power

Cut-off Control

Circuit

Noise Filter

Class D

Grounding Work

(Protective

Ground)

PIO Power

Supply (24V DC)
