16. Controller

227

210

③

Servo ON

F1 (OK) key.

④

Homing

F1 (OK) key.

⑤

Servo OFF

After executing absolute reset, be sure to reset

software or reconnect the power. Do not press the

F1 (OK) key but press the PAGE UP key. Then

move to “⑥ Encoder multi-rotation data reset 2.”

⑥

Encoder multi-rotation data reset 2

Press the F1 (OK) key.

Default Chapter7
