16. Controller

241

221

③

Servo ON

Press the F1 (OK) key.

④ Temporary standard posture standby

Press the F1 (OK) key.

Note: The Z-axis returns to the home position.

⑤

Jog movement

Move the R-axis to the vicinity of the basic

position with jog keys (see the “Standard Posture

Drawing” on the next page).

Press the F1 (OK) key.

⑥

Servo OFF

Press the F1 (OK) key.
