IAI SEL User Manual

16. Controller
260
Home preset value auto refresh
Press the F1 (OK) key.
Adjusting jig removal and emergency off
Remove the adjusting jig.
Turn off the brake release switch to enable the
brake.
Turn off the EMERGENCY STOP button.
Press the F1 (OK) key.
Return to the previous screen with the ESC key.
If “Write Flash ROM?” is displayed, exit the
screen with “Yes.”
Restart the controller.
Press the F1 (Yes) key.
Writing Flash ROM.
1

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
