IAI SEL User Manual

* Supplement
294
234
Press the PAGE UP key to advance the screen,
without pressing the F1 (OK) key.
Press the F1 (OK) key.
③ Execute the “encoder multi-rotation data reset 1” for the slave axis again.
Input the axis No. of the slave axis again and press
the return key.
Press the F1 (OK) key.
Press the F1 (OK) key.
Exit from the absolute reset mode with the ESC key,
without pressing the F1 (OK) key.
Restart the controller.
Press the F1 (Yes) key.

IAI SEL Specifications

General

Protection Class	IP20
Communication	RS-232C
Control Method	PTP
Number of Axes	Up to 4 axes
Vibration Resistance	4.9 m/s² (0.5 G)
Humidity	20 to 85% RH (non-condensing)
