5. How to Save Data
29
For the X-SEL-P/Q and PX/QX controllers with the gateway function, the position Nos. 10001 to
20000 data memory and user hold memory (RC axis position in XSEL) have been added.
(Other parameter No.20=0 (System memory backup battery unequipped))
Edit data with PC or
Teaching Pendant
Save the data during the
power is on and delete
the data by reset
Save data even after the power OFF
Flashe write
Reset read
Reset read
Transmit
Transmit
Transmit
Transmit
Transmit
Reset read
Reset read
Memory
Memory
Memory
Memory
Memory
*Encoder
Flash
memory
Flash
memory
Program
parameter
(content 1)
Symbol
position
Slave card
parameter
(content 2)
*Encoder
parameter
SEL global data
(content 3)
Error list
User Hold
Memory
(RC axis position
in XSEL)
Transmit
Transmit
Flashe write
to
The program parameter symbol position is downloaded from the ash memory when the machine
is re-started. Therefore, when the data is not written in the flash memory, the old date before
editing is held in the memory and downloaded when the machine is re-started.
The controller is always operated according to the data in the memory (within the dot lines). (Except
for the parameters)
Caution: The SEL global data is not held when the backup battery is not attached.
