IMT CMD.CTRL - Page 157

Body Codes 139 Section - 20
Operator’s - Manual # 99906363
HELP
MESSAGE DTC
STOP
ICON
WARN
ICON ACTION TRIGGER LATCH
Right Rear
Stabilizer Retract
– Open Circuit
2343 OFF ON • No restrictions
Open Circuit detected on Right
Rear Stabilizer Retract Output.
Unlatched
Vehicle must be congured to
have an extendable right rear
stabilizer installed.
Right Rear
Stabilizer Retract
– Short To Battery
2344 OFF ON
• Disable Bypass
Valve
Short to Battery detected on Right
Rear Stabilizer Retract Output.
Unlatched
Vehicle must be congured to
have an extendable right rear
stabilizer installed.
Right Rear
Stabilizer
Retract – Short To
Ground
2345 OFF ON • Disable Output
Short to Ground was detected
on Right Rear Stabilizer Retract
Output.
Latched
Vehicle must be congured to
have an extendable right rear
stabilizer installed.
Front Stabilizer
Down – Open
Circuit
2346 OFF ON • No restrictions
Open Circuit detected on Front
Stabilizer Down Output.
Unlatched
Vehicle must be congured to
have a front stabilizer installed.
Front Stabilizer
Down – Short To
Battery
2347 OFF ON
• Disable Bypass
Valve
Short to Battery detected on Front
Stabilizer Down Output.
Unlatched
Vehicle must be congured to
have a front stabilizer installed.
Front Stabilizer
Down– Short To
Ground
2348 OFF ON • Disable Output
Short to Ground was detected on
Front Stabilizer Down Output.
Latched
Vehicle must be congured to
have a front stabilizer installed.
Front Stabilizer
Up – Open Circuit
2349 OFF ON • No restrictions
Open Circuit detected on Front
Stabilizer Up Output.
Unlatched
Vehicle must be congured to
have a front stabilizer installed.
Front Stabilizer
Up – Short To
Battery
2350 OFF ON
• Disable Bypass
Valve
Short to Battery detected on Front
Stabilizer Up Output.
Unlatched
Vehicle must be congured to
have a front stabilizer installed.
Front Stabilizer
Up – Short To
Ground
2351 OFF ON • Disable Output
Short to Ground was detected on
Front Stabilizer Up Output.
Latched
Vehicle must be congured to
have a front stabilizer installed.
Front Stabilizer
Extend – Open
Circuit
2352 OFF ON • No restrictions
Open Circuit detected on Front
Stabilizer Extend Output.
Unlatched
Vehicle must be congured
to have an extendable front
stabilizer installed.
Front Stabilizer
Extend – Short To
Battery
2353 OFF ON
• Disable Bypass
Valve
Short to Battery detected on Front
Stabilizer Extend Output.
Unlatched
Vehicle must be congured
to have an extendable front
stabilizer installed.
Front Stabilizer
Extend – Short To
Ground
2354 OFF ON • Disable Output
Short to Ground was detected on
Front Stabilizer Extend Output.
Latched
Vehicle must be congured
to have an extendable front
stabilizer installed.
Front Stabilizer
Retract – Open
Circuit
2355 OFF ON • No restrictions
Open Circuit detected on Front
Stabilizer Retract Output.
Unlatched
Vehicle must be congured
to have an extendable front
stabilizer installed.
