IMT CMD.CTRL - Page 158

Body Codes 140 Section - 20
Operator’s - Manual # 99906363
HELP
MESSAGE DTC
STOP
ICON
WARN
ICON ACTION TRIGGER LATCH
Front Stabilizer
Retract – Short To
Battery
2356 OFF ON
• Disable Bypass
Valve
Short to Battery detected on Front
Stabilizer Retract Output.
Unlatched
Vehicle must be congured
to have an extendable front
stabilizer installed.
Front Stabilizer
Retract – Short To
Ground
2357 OFF ON • Disable Output
Short to Ground was detected on
Front Stabilizer Retract Output.
Latched
Vehicle must be congured
to have an extendable front
stabilizer installed.
Engine Start –
Short To Battery
2359 OFF ON
• Engine
Start/Stop =
PREVENTED
Short to Battery detected on
Engine Start Output
Unlatched
Engine Start –
Short To Ground
2360 OFF ON • Disable Output
Short to Ground was detected on
Engine Start Output
Latched
Engine Stop –
Open Circuit
2361 OFF ON • No restrictions
Open Circuit detected on Engine
Stop Output
Latched
Note: This Fault will not be
detected Pull Up resister
removed.
Engine Stop –
Short To Battery
2362 OFF ON
• Engine
Start/Stop =
PREVENTED
Short to Battery detected on
Engine Stop Output
Unlatched
• IPU Power latch
= PREVENTED
Vehicle must be congured to not
be the RAM Chassis
Engine Stop –
Short To Ground
2363 OFF ON • Disable Output
Short to Ground was detected on
Engine Stop Output
Latched
Vehicle must be congured to not
be the RAM Chassis
Engine Speed 1 –
Short To Battery
2365 OFF ON • No restrictions
Short to Battery detected on
Engine Speed 1 Output
Unlatched
Engine Speed 1–
Short To Ground
2366 OFF ON • Disable Output
Short to Ground was detected on
Engine Speed 1 Output
Latched
Engine Speed 2 –
Short To Battery
2368 OFF ON • No restrictions
Short to Battery detected on
Engine Speed 2 Output.
Unlatched
Vehicle must be congured to
have dual engine RPM speeds.
Engine Speed 2–
Short To Ground
2369 OFF ON • Disable Output
Short to Ground was detected on
Engine Speed 2 Output.
Latched
Vehicle must be congured to
have dual engine RPM speeds.
Transmission
Inhibit – Open
Circuit
2370 OFF ON • No restrictions
Open Circuit detected on
Transmission Inhibit Output
Unlatched
Vehicle must be congured to
have Transmission Inhibit
Transmission
Inhibit – Short To
Battery
2371 OFF ON • No restrictions
Short to Battery detected on
Transmission Inhibit Output
Unlatched
Vehicle must be congured to
have Transmission Inhibit
Transmission
Inhibit– Short To
Ground
2372 OFF ON • Disable Output
Short to Ground was detected on
Transmission Inhibit Output
Latched
Vehicle must be congured to
have Transmission Inhibit
Master Lock
Open – Open
Circuit
2373 OFF ON • No restrictions
Open Circuit detected on Master
lock Open Output.
Unlatched
Vehicle must be congured to
have Master lock installed.
