IMT CMD.CTRL - Page 159

Body Codes 141 Section - 20
Operator’s - Manual # 99906363
HELP
MESSAGE DTC
STOP
ICON
WARN
ICON ACTION TRIGGER LATCH
Master Lock
Open – Short To
Battery
2374 OFF ON • No restrictions
Short to Battery detected on
Master lock Open Output.
Unlatched
Vehicle must be congured to
have Master lock installed.
Master Lock
Open – Short To
Ground
2375 OFF ON • Disable Output
Short to Ground was detected on
Master lock Open Output.
Latched
Vehicle must be congured to
have Master lock installed.
Master Lock
Close – Open
Circuit
2376 OFF ON • No restrictions
Open Circuit detected on Master
lock Close Output.
Unlatched
Vehicle must be congured to
have Master lock installed.
Master Lock
Close – Short To
Battery
2377 OFF ON • No restrictions
Short to Battery detected on
Master lock Close Output.
Unlatched
Vehicle must be congured to
have Master lock installed.
Master Lock
Close – Short To
Ground
2378 OFF ON • Disable Output
Short to Ground was detected on
Master lock Close Output.
Latched
Vehicle must be congured to
have Master lock installed.
Left Compartment
Light – Open
Circuit
2379 OFF ON • No restrictions
Open Circuit detected on Left
Compartment Light Output
Unlatched
Left Compartment
Light – Short To
Battery
2380 OFF ON • No restrictions
Short to Battery detected on Left
Compartment Light Output
Unlatched
Left Compartment
Light – Short To
Ground
2381 OFF ON • Disable Output
Short to Ground was detected on
Left Compartment Light Output
Latched
Right
Compartment
Light – Open
Circuit
2382 OFF ON • No restrictions
Open Circuit detected on Right
Compartment Light Output
Unlatched
Right
Compartment
Light – Short To
Battery
2383 OFF ON • No restrictions
Short to Battery detected on
Right Compartment Light Output
Unlatched
Right
Compartment
Light – Short To
Ground
2384 OFF ON • Disable Output
Short to Ground was detected on
Right Compartment Light Output
Latched
Auxiliary 1 –
Short To Ground
2385 OFF ON • Disable Output
Short to Ground was detected on
Auxiliary 1 Output
Latched
Auxiliary 2 –
Short To Ground
2386 OFF ON • Disable Output
Short to Ground was detected on
Auxiliary 2 Output
Latched
Right Front Flood
Light – Short To
Ground
2387 OFF ON • Disable Output
Short to Ground was detected on
Right Front Flood Light Output.
Latched
Vehicle must be congured to
have the right front ood light
installed.
Right Middle
Flood Light –
Short To Ground
2388 OFF ON • Disable Output
Short to Ground was detected on
Right Middle Flood Light Output.
Latched
Vehicle must be congured to
have the right middle ood light
installed.
Right Rear Flood
Light – Short To
Ground
2389 OFF ON • Disable Output
Short to Ground was detected on
Right Rear Flood Light Output.
Latched
Vehicle must be congured to
have the right rear ood light
installed.
