IMT CMD.CTRL - Page 160

Body Codes 142 Section - 20
Operator’s - Manual # 99906363
HELP
MESSAGE DTC
STOP
ICON
WARN
ICON ACTION TRIGGER LATCH
Left Front Flood
Light – Short To
Ground
2390 OFF ON • Disable Output
Short to Ground was detected on
Left Front Flood Light Output.
Latched
Vehicle must be congured to
have the left front ood light
installed.
Left Middle Flood
Light – Short To
Ground
2391 OFF ON • Disable Output
Short to Ground was detected on
Left Middle Flood Light Output.
Latched
Vehicle must be congured to
have the left middle ood light
installed.
Left Rear Flood
Light – Short To
Ground
2392 OFF ON • Disable Output
Short to Ground was detected on
Left Rear Flood Light Output.
Latched
Vehicle must be congured to
have the left rear ood light
installed.
CAN Bus Failure
– Display
662 OFF ON
• Stabilizer =
PREVENTED
The Body Module failed to
receive messages from the
Display. Check wiring at the
Display.
• Functions Request Message –
(0x0B) not received for 30000mS
upon Startup and 250mS
thereafter.
Latched
• Crane Enable =
PREVENTED
• Compressor =
PREVENTED
• PTO =
PREVENTED
• Engine
Start/Stop =
PREVENTED
• Compartment
Fans =
PREVENTED
• Horn =
PREVENTED
CAN Bus
Failure – Remote
Stabilizer Module
663 OFF ON
• Front Stabilizer =
PREVENTED
The Front Stabilizer is congured
and the Body Module failed
to receive messages from the
Remote I/O Module. Check
wiring at the Remote I/O Module.
Latched
•Remote I/O Status Message –
(0x47) not received for 300mS.
Vehicle must be congured to
have a front stabilizer installed.
CAN Bus Failure
– Chassis Tilt
Sensor
669 OFF ON
• AUTO LEVEL =
PREVENTED
When the Chassis Tilt sensor is
congured and the Crane Module
failed to receive messages from
the Parker tilt Sensor for 250
msec.
Latched
• Chassis
tilt sensor =
UNHEALTHY
CAN Bus Failure
– Crane Module
6610 OFF ON
• Stabilizer and
Auto Level
Control from
Remote/Crane =
PREVENTED
The Body Module failed to
receive messages from the Crane
Module. Check wiring at the
Crane.
Latched
• Functions Request Message –
(0x23) not received for 250mS.
Crane needs to be congured as
a Hydraulic Gen 2 system
