INTERCHANGEABLE HEAD STRIKERS (Table 1 of 2)
a) for striker code 7519.694 only.
7519.001 7519.694 7519.696 7519.504 7519.505 7519.506 7519.507 7519.606
STRIKERS HEADS
non-
instrum.
piezo
4.5 kN
piezo
22 kN
strain
gauge
5 kN
strain
gauge
10 kN
strain gauge
20 kN
strain gauge
40 kN
piezo
22 kN
7529.802
7529.801 (a)
Ø 12.7 mm
ASTM D 3763 ASTM D 7192
L 240 mm
P 487 g
L 239 mm
P 486 g
Length 240 mm; Mass 487 g
7529.803
Ø 15.86 (5/8 ”)
ASTM D 5628 FA
ASTM D7136, Boeing
BSS 7260 SACMA
SRM 2R-94
Length 240 mm; Mass 566 g
7529.825
Ø 16 mm
AECMA EN6038,
ASTM D7136 M, Airbus
AITM 1.0010
Length 240 mm; Mass 568 g
-
7529.826
Ø 16 mm
Airbus AITM 1.0010,
ASTM D7136, ASTM
D7136 M, AECMA
EN6038, SACMA SRM
2R-94, Boeing BSS
7260
Length 250 mm; Mass 608 g
7529.804
Ø 20 mm
ISO 6603 - ISO 7765
ASTM D5628 met. FE
Length 245 mm; Mass 605 g
7529.806 Ø 25.4 mm Length 247 mm; Mass 635 g 7529.807
Ø 38.1 mm
ASTM D5628 met. FC
Length 241 mm; Mass 648 g
