CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1 - Page 163
INTERCHANGEABLE HEAD STRIKERS (Table 2 of 2)
7519.001 7519.694 7519.696 7519.504 7519.505 7519.506 7519.507 7519.606
STRIKERS HEADS
non- instrum.
piezo
4.5 kN
piezo
22 kN
strain
gauge
5 kN
strain gauge
10 kN
strain gauge
20 kN
strain gauge
40 kN
piezo
22 kN
7529.840
Ø 12.7 mm conical
ASTM D5628 met. FB
Length 255 mm; Mass 650 g
7529.841 for pipes D 2444 type A Length 262 mm; Mass 770 g 7529.842 for pipes D 2444 type B Length 247 mm; Mass 768 g 7529.843 for pipes D 2444 type C Length 253 mm; Mass 739 g 7529.830 flat Ø 50 mm Length 245 mm; Mass 704 g 7529.810
Izod
ASTM D256 - ISO 180
Length 275 mm; Mass 641 g
7529.811 Charpy ASTM D6110 Length 255 mm; Mass 623 g 7529.812 Charpy ISO 179 Length 267 mm; Mass 640 g 7529.820 Izod ASTM E 23 Length 275 mm; Mass 641 g 7529.821 Charpy ASTM E 23 Length 265 mm; Mass 639 g
