Page 168 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1
OUTPUT LIST (2 of 2)
Output Meaning IF
ACTIVE (logic
state "1" writed
by CPU -- LED
on board ON--
Output driven
toward positive
reference)
Power Supply Actuator Notes
9 INV_OUT_1
(M5-3
LED D 52)
Start Movement
Crosshead go
down
(encoder
decrement)
P24_INV
P24 (generated
by inverter)
MI1 Terminal
(FWD) inverter
10 INV_OUT_2
(M5-4
LED D 53)
Start Movement
Crosshead go up
P24_INV
P24 (generated
by inverter)
MI2 Terminal
(REV) inverter
11 INV_OUT_3
(M5-5
LED D 54)
Crosshead speed
selection (bit1)
P24_INV
P24 (generated
by inverter)
MI3 Terminal,
inverter
12 INV_OUT_4
(M5-6
LED D 58)
Crosshead speed
selection (bit2)
P24_INV
P24 (generated
by inverter)
MI4 Terminal,
inverter
13 INV_OUT_5
(M5-7
LED D 59)
Crosshead motor
DC braking
P24_INV
P24 (generated
by inverter)
MI5 Terminal,
inverter
14 INV_OUT_6
(M5-8
LED D 60)
Buzzer active P24_INV_6
P24
Buzzer
15 INV_OUT_7
(M5-9
LED D 63)
Activate the power
reinstate
P24_INV_7
P24_DOOR
Power the NA
section of the two
door sensors
series connected
Restore the power
after door shutting
(both doors: turret
and chamber)
16 INV_OUT_8
(M5-10
LED D 64)
Thermostatic
chamber ON
P24_INV_8
P24_DOOR
Chamber power
relay
Activate the power
for heating, fan and
EV nitrogen
