Page 174 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1
List of Error Codes (
Movements/Process Errors. They cause the test to stop
)
1 of 4
Code Error Cause Remedy
404 TV: crosshead target
movement over upper limit
405 TV: crosshead target
movement under lower limit
408 TV: shutter closed
412 Specimen not clamped in time Specimen clamping plate do
not descend
413 Specimen not removed in time Specimen clamping plate do
not ascend
Contact Authorized Service
415 Timeout striker: no picking Contact Authorized Service
416 Timeout striker: release did not
occur
Contact Authorized Service
418 Shock absorbers out of
position
Contact Instron Service
419 No striker release: shutter
closed
Contact Instron Service
420 No striker picking Contact Instron Service
421 Striker releasing system
closed without striker inside
Emergency button pressed
before the lifter picks up the
striker
Perform an "Home" cycle
(press the "Home" key)
