Page 68 - CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1
Fig. 2 - Fixture for Charpy test with shoulders according to ASTM E-23 standard
(notched metallic specimen)
Fig. 3 - Fixture for Charpy test with shoulders according to ISO standards
(notched and unnotched plastic specimens)
Fig. 3 A - Notched
specimen
Fig. 3 B - Unnotched
specimen
Stop plate
Screw
Notch
downward
Notch
centering pin
Metallic
specimen
Notch
downward
Notch
centering pin
Plastic
specimen
Plastic
specimen
Alignment
pin (x 2)
Alignment
pin (x 2)
