CEAST 9340 - Instructions for Use and Maintenance 7510.000MN1r ed. 1 rev. 1 - Page 79
Fig. 2 - Instrumented striker installed on the instrument
Route for
signal cable
Signal cable
holder
Clamp
The signal cable coming from the striker
must pass through the three harmonic wire
eyelets indicated by the arrows
Screw (x2)
Instrumented
Striker
Signal cable
Clamp
Signal cable to the DAS
Data Acquisition System
Signal cable
Detail A
Detail C
Detail D
Detail E
Detail B
