IPCGansow CT 230 BT 85 - Detergent Tank Float Switch

PLDC01938
REVISION 00
01/06/2011
TECHNICAL DEPT.
Stavale
- date 05/09/2011 123/195
Detergent tank float switch
The magnet is distant from the
flexible metal strip and the circuit
is therefore open.
The digital multimeter will not
detect electrical continuity.
PHOTO 264
The magnet is near the flexible
metal strip and the circuit is
therefore closed.
The digital multimeter will detect
electrical continuity.
CLIC
A
B
B
A
