B2.1 Checking the current draw of the electromechanical actuator
1
Make sure the batteries on the machine are charged (36 V ± 1 V).
2
Obtain a clamp meter able to read up to 200 A (amps).
3
Move the machine to the tank draining area and completely empty both tanks.
4
Move the machine onto a flat dry area of floor.
5
Make sure there is sufficient space around the machine to carry out the tests safely.
6
Switch the machine off by turning the ignition key A to "0" and press the pedal B to put the parking brake on.
7
Unscrew knob C and lift both tanks to facilitate access to the fuse holder assembly F and Anderson
connector D.
8
Identify the fuse F3 of the electromechanical actuator E.
PHOTO 180
B
PHOTO 181
F
D
PHOTO 182
F3
