In case of emergency
If the "Motor Temperature PAUSE" warning is displayed when the motor is cold and you need
to move the machine, you can create a temporary by-pass connection (to be restored as soon
as possible) to exclude the control panel control unit and enable the machine to be moved.
8
Disconnect the wires D of the thermal cutout G7 and connect them together.
9
Disconnect the main thermal cutout wires E and connect them together.
Reassembly
1
Remount the casing A on the drive motor.
2
To replace the thermal cutout, see the previous paragraph. Restore the electrical connection.
PHOTO 319
E
