PLDC01938
REVISION 00
01/06/2011
TECHNICAL DEPT
Stavale
- date 05/09/2011
186/195
E1 ERROR CODES
E1.1 Curtis drive board alarms
The drive board status is displayed by means of an LED on the control panel. During normal
operation, the LED is on steadily. When there is a malfunction, the LED flashes. The frequency
of flashing indicates the severity of the malfunction. Slow flashing (2 Hz) identifies malfunctions
which, after being repaired, are cancelled automatically and the machine begins to operate
correctly again. Slow flashing (4 Hz) errors indicated in the table with an asterisk (*) are much
more serious and once repaired require the machine to be turned off by means of the ignition
key to reset correct operation.
The indication of malfunction severity remains for about ten (10) seconds, after which the LED
displays the cause of the error by means of a two digit code expressed by lighting of the LED in
sequence.
PHOTO 374
