PLDC01938
REVISION 00
01/06/2011
TECHNICAL DEPT.
Stavale
- date 05/09/2011
64/195
A5.1 Cleaning the solenoid valve
Disassembly
1
Check there is water or detergent in the detergent tank. If it is empty, add a little water.
2
Move the machine onto a flat area of floor.
3
Brake the machine by pressing pedal A to put the parking brake on.
4
Unscrew the knob B by turning it anticlockwise to release the dirty water and detergent tanks.
5
Raise the detergent and dirty water tanks.
6
Press the button C to command brush release then remove the brushes from under the head.
7
Wait for the LED indicating that the brushes can be attached to flash. Press button C again to perform an
automatic brush attachment operation without attaching the brushes.
8
With the head fully lowered, press the
emergency button D to block the position and
avoid the head returning to the standby
position.
9
Disconnect the batteries by means of the
connector E, turn the ignition key to position
“0”, restore the emergency button D to the
original position.
B
A
PHOTO 142
C C
PHOTO 143
PHOTO 144
E
