Section 7 iPRO-RC™ Series Banknote Recycler Exploded Views and Parts Lists
iPRO-RC RC Space 1 Parts List
Table 7-7 iPRO-RC RC Space 1 Parts List
Ref No. EDP No. Description Qty Remark
600 251308 Door 1
601 080522 Personal Coin Lock Mini 1
6
02 195897 Tang 1
60
3
and
604
196462 Length Guide 120 (Gray)
1
Choose two guides
of the seven
various guides.
*
*. Refer to the “Software Information Sheet” to choose appropriate guides for each currency.
196464 Length Guide 127 (Red) 1
196466 Length Guide 133 (Blue) 1
196
468 Length Guide 140 (Orange) 1
196
469 Length Guide 147 (Green) 1
204
457 Length Guide 152 (Black) 1
196
470 Length Guide 158 (Black) 1
6
05 195917 Length Guide Assist Sheet 1
6
06 195888 Fulcrum Shaft 2
6
07 195915 RC Skid 2
6
08 265781 Front Width Guide 4
6
09 195916 RC Pressure Guide 2
6
10 003609 M3x6 W Washer (Small) 8
61
1 081564 M2.6x5 Flat Head Screw (Nyloc) 4
6
12 063352 M2.3x5 Washer 2
6
13 138053 2x5 Phillips, Self Tightening, Binding 2
6
14 003707 ø3 E-Ring 2
6
15 226493 RC Lock Guide 1 For P-Lock
6
16 226494 RC Lock Lever 1 For P-Lock
6
17 226495 RC Lock 1 For P-Lock
6
18 226496 RC Lock Spring 1 For P-Lock
6
19 104010 M3.6x6 Phillips, Self-Tapping, Bind Head Screw 1 For P-Lock
6
20 003610 M3x6 W Washer (Large) 4
To Next Page
