Section 7 iPRO-RC™ Series Banknote Recycler Exploded Views and Parts Lists
iPRO-RC RC Space 4 Parts List
Table 7-10 iPRO-RC RC Space 4 Parts List
Ref No. EDP No. Description Qty Remark
900 195890 RC Frame Assy Left 1
901 195880 Rack Guide Roller 4
90
2 195911 Width Guide Left 1
9
03 195876 Rack Gear Left 1
9
04 195895 Lifter Left 2
9
05 195922 Pick Helical Extension Spring 4
9
06 195891 RC Frame Assy Right 1
9
07 195873 Idle Gear Z20 3
9
08 195912 Width Guide Right 1
9
09 195877 Rack Gear Right 1
9
10 195896 Lifter Right 2
91
1 110909 Prism (C) 1
9
12 195946 M3x4 Binding (Nyloc) 8
9
13 005555 M2.6x6 W Washer (Small) 10
9
14 081564 M2.6x5 Flat Head Screw (Nyloc) 2
9
15 003705 ø2 E-Ring 4
To Next Page
