JCM iPRO-100-SH2-RC User Manual

P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
7-2
Section 7 iPRO-RC™ Series Banknote Recycler Exploded Views and Parts Lists
Entire iPRO-RC Unit Parts List
Table 7-1 iPRO-RC Unit Parts List
Ref No. EDP No. Description Qty Remark
1
196488 UBA/iPRO-RC Frame 1
216287 UBA/iPRO-RC Frame (Large Cash Box) 1
2
207
618 iPRO-100 Transport Unit 1
210
726 iPRO-200 Transport Unit 1
236
850 iPRO-100 Transport Unit OEM 1
3
198102 Bezel Spacer 1
4
202
272 UBA/iPRO Bezel SS 1 R (85mm, Black, Green LED) 1
No
Relay Harness
Bezel Harness:
#200399
202273 UBA/iPRO Bezel SS 2 R (85mm, Blue, Blue LED) 1
202
275 UBA/iPRO Bezel SS A R (85mm, Bl
ue, Blue LED. 2-Line) 1
Relay Harness:
#
196594
Bezel Harness:
#200399
202276 UBA/iPRO Bezel SS B R (85mm, Green, Green LED. 2-Line) 1
202
277 UBA/iPRO Bezel SS Metal M1 (Metal, Silver, Green LED) 1
No
Relay Harness
Bezel Harness:
#200399
202278 UBA/iPRO Bezel SS Metal M2 (Metal, Silver, Blue LED) 1
5
195
963 UBA/iPRO-RC RC Space 1
237347 UBA/iPRO-RC RC Space with Anti Static Sheet 1
226497 UBA/iPRO-RC RC Space with P-Lock (Plastic Simple Lock) 1
6
131
854 WBA-SH2 Cash Box Unit 1
127891
UBA/iPRO Large Cash Box with Key Spacers and Tangs
*
*. Refer to the iPRO Series Banknote Acceptor Operational and Maintenance Manual for the Exploded View and Parts List.
1
7 075245 Grommet 1
8 199082 M3x35 W Washer (Small) 2 Accessory
9
013536 M3x10 W Washer (Small) 2 Accessory
10
209
567 External Communication Harness (Standard) 1 Accessory
N/A External Communication Harness (USB/IF) 1 Accessory
222
912 External Communication Harness for OEM(3441-05-03) 1 Accessory
196
554 External Communication Harness for OEM (3440-05-10) 1 Accessory
1
1 196555 Power Harness 1 Accessory
OP
206442 Lock Unit Assy. 1 Optional
