Installation iPRO-RC™ Series Banknote Recycler Section 2
Connector Pin Assignments (Continued)
Table 2-6 lists the Photo Coupler Interface Connector Pin Assignments.
Table 2-6 Photo Coupler Interface Connection Pin Assignments
Socket (Transport Unit Side): DRA-20PC-FO (JAE)
Contact (Transport Unit Side): D02-22-26P-10000 (JAE)
Socket (Frame Side): DRA-20SC-FO (JAE)
Contact (Frame Side): D02-22-26S-10000 (JAE)/D02-22-22S-10000 (JAE) (Terminal# 3, 13)
Recommended Wires: Slit Wire UL1061 AWG #26
Pin No. Signal Name
I/O
*
*. I/O (input/output) is the terminal as viewed from the Banknote Recycler’s backside.
Function
1-- -Reserved
2-- -Reserved
3 M.RES IN Acceptor Hard Reset Signal Line
4 TXD OUT Output Signal Line from Acceptor to Host
5-- -Reserved
6 RXD IN Input Signal Line from Host to Acceptor
7 GND (I/F) - Interface Power Supply (Photo Coupler 0V DC)
8 NC - No Connection
9 NC - No Connection
10 NC - No Connection
11 -- - Reserved
12 NC - No Connection
13 NC - No Connection
14 LED (Power) - LED Drive Line (Anode)
15 -- - Reserved
16 NC - No Connection
17 -- - Reserved
18 LED - LED Drive Line (Cathode)
19 NC - No Connection
20 -- - Reserved
To Next Page
