Section 7 iPRO-RC™ Series Banknote Recycler Exploded Views and Parts Lists
WBA-SH2 Cash Box Parts List 4
Table 7-21 WBA-SH2 Cash Box Parts List 4
Ref No. EDP No. Description Qty Remark
2000 070740 Pusher Plate 82 1
2001 081620 O-Ring 6
200
2 052557 Pusher Link 1 1
200
3 070749 Upper Arm Pin 82 1
200
4 070750 Left Arm Shaft 82 1
200
5 070741 Pusher Link 2 82 2
200
6 070748 Upper Right Shaft 82 2
200
7 052580 Arm Roller 1 2
200
8 064413 SH Pusher Rack 1
200
9 052579 Right Guide Roller 1
201
0 064424 Spring Bushing 1
2
011 052631 Right Roller Pin 2
201
2 064521 SH Pusher Spring 1
201
3 052628 Left Arm Shaft 1
201
4 052626 Gear Roller Shaft 1
201
5 064401 SH Pusher Base 1
201
6 003707 ø3 E-Ring 8
201
7 003705 ø2 E-Ring 4
