P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
iPRO-RC™ Series
Banknote Recycler
Appendix B
B GLOSSARY
A
1 Anti-Pullback Mechanism
The rotating drum located in the rear portion of the transport to prevent a Banknote
from being retrieved by an attached piece of string, wire or transparent tape ... 1-4
B
2 Banknote Guide
a specific length and width shim designed to center and limit a specific Country’s
Banknote size for proper transport through the Validator ... A-5
3 Bezel
a removable Plastic Assembly attached to the front of the Banknote Insertion Slot of an
iPRO Unit. It features, a rectangular access slot for easy insertion and retrieval of
Banknotes. Bezels are available in different shapes and sizes in order to accommodate
Banknotes of different widths and a different stacking configuration ... 1-2
C
4 Centering Mechanism
a mechanical assembly designed to center Banknotes that enter the Validator at skewed
angle ... 1-4
5 Current Limiting Power Source
an electronic circuit designed to prevent damage to a Power Supply in the event a short
circuit occurs ... 1-7
D
6DIP Switch
an acronym for Dual In-line Package Switch - a mountable two-position slide switch
containing up to 16 individual Switches per block assembly located on a Printed Circuit
Board (PCB), which may be set to an ON or OFF position. DIP Switches are often used
in circuits where manual selection of operational changes, options and features are de-
sired ... 2-2
E
7E-Clip
a semicircular retainer clip with center tab forming the letter “E” designed to fit into a
shaft groove to retain a component in place, and having hole rings, at its ends for inser-
tion of special expansion/removal/replacement tool tips ... 4-1
