JCM iPRO-100-SH2-RC User Manual

P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
2-4
Section 2 iPRO-RC™ Series Banknote Recycler Installation
Connector Pin Assignments
Table 2-5 lists the USB Interface Connector Pin Assignments.
Table 2-5 USB Interface Connection Pin Assignments
Socket (Transport Unit Side): DRA-20PC-FO (JAE)
Contact (Transport Unit Side): D02-22-26P-10000 (JAE)
Socket (Frame Side): DRA-20SC-FO (JAE)
Contact (Frame Side): D02-22-26S-10000 (JAE)/D02-22-22S-10000 (JAE) (Terminal# 3, 13)
Recommended Wires: Slit Wire UL1061 AWG #26
Pin No. Signal Name
I/O
*
*. I/O (input/output) is the terminal as viewed from the Banknote Recycler’s backside.
Function
1-- -Reserved
2-- -Reserved
3 M.RES IN Acceptor Hard Reset Signal Line
4 NC - No Connection
5-- -Reserved
6 NC - No Connection
7 NC - No Connection
8 Vbus IN USB Communication Vbus Signal Line (+5V DC)
9 -DATA IN/OUT USB Communication Input/Output Signal Line
10 +DATA IN/OUT USB Communication Input/Output Signal Line
11 -- - Reserved
12 GND (USB) - USB Communication Ground (0V DC)
13 NC - No Connection
14 LED (Power) - LED Drive Line (Anode)
15 -- - Reserved
16 NC - No Connection
17 -- - Reserved
18 LED - LED Drive Line (Cathode)
19 NC - No Connection
20 -- - Reserved
