P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
General Information iPRO-RC™ Series Banknote Recycler Section 1
Environmental Specifications
Electrical Specifications
Structural Specifications
Table 1-5 iPRO-RC Environmental Specifications
Operating Temperature: 5ºC to +50ºC (41ºF to 122ºF)
Storage Temperature: -20ºC to +60ºC (-4ºF to 140ºF)
Relative Operating Humidity: 30% to 85% RH (non-condensing)
Relative Storage Humidity: 30% to 85% RH (non-condensing)
Visible Light Sensitivity: Avoid contact with direct Sunlight
Installation: Indoors Only
Table 1-6 iPRO-RC Electrical S
pecifications
Supply Voltage
*
:
*. Use a Limited Power Source.
24V DC (±5%) (Greater than 3.5A Recommended)
(Use a Current Limiting Power Source)
Current Consumption:
Standby: 230mA
Operation: 1.5A
Peak: 2.5A
Table 1-7 iP
RO-RC Structural Specifications
Weight Empty: Approximately 9kg (19.8lbs)
Mounting: Horizontal
Outside Dimensions:
Refer to Figure 1-6 “iPRO-RC Banknote Recycler Standard Unit with
Bezel Outside Dimensions” on page 1-8 of this Service Manual Section.
Hydrothermal Condition Table
[°C]
[RH%]
35°C/85%
50°C/40%
[°C]
[RH%]
40°C/70%
50°C/40%
Normal Banknote
Polymer Banknote
Allowable Operating
Temperature and
Humidity Range
Allowable Operating
Temperature and
Humidity Range
To Next Page
