JCM iPRO-100-SH2-RC User Manual

P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
7-1
iPRO-RC™ Series
Banknote Recycler
Section 7
This section provides product exploded views and
parts lists for iPRO-RC™ Series Banknote Recy-
cler (iPRO-100-SH2-RC; iPRO-RC™) Unit. This
section contains the following information.
• Entire iPRO-RC Unit Exploded View
• iPRO-RC Frame Unit Exploded View
• iPRO-RC Lower Unit
• iPRO-RC Upper Course Assembly
• iPRO-RC RC Space Unit Exploded View
• iPRO-RC Rear Transport Assembly 
Exploded View
• WBA-SH2 Cash Box Unit Exploded View
• iPRO-RC Large Cash Box Frame Unit
Exploded View
• Optional Lock Unit Exploded View
7 EXPLODED VIEWS AND PARTS LISTS
NOTE: Parts may be changed for
improvement without notice.
Figure 7-1 Entire iPRO-RC Unit Exploded View
Entire iPRO-RC Unit Exploded View
1
2
3
4
8
5
7
6
1
6
OP
OP
11
10
9
Figure 7-1 Entire iPRO-RC Unit Exploded View
