JCM iPRO-100-SH2-RC User Manual

P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
7-4
Section 7 iPRO-RC™ Series Banknote Recycler Exploded Views and Parts Lists
iPRO-RC Frame Unit 1 Parts List
Table 7-2 iPRO-RC Frame Unit 1 Parts List
Ref No. EDP No. Description Qty Remark
100 265015 RC Bezel Assy. 1
101 196443 UBA/iPRO-RC Upper Frame 1
102 265780 UBA/iPRO Transport Rail 2
103 196441 UBA/iPRO-RC Rear Frame 1
104 128427 M3x5 Flat Head Screw (Nyloc) 2
105 006036 M3x4 Washer 12
106 149635 M3x4 Low Head Flat Screw (Nyloc) 4
