JCM iPRO-100-SH2-RC User Manual

P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
7-6
Section 7 iPRO-RC™ Series Banknote Recycler Exploded Views and Parts Lists
iPRO-RC Frame Unit 2 Parts List
Table 7-3 iPRO-RC Frame Unit 2 Parts List
Ref No. EDP No. Description Qty Remark
200 196440 UBA/iPRO-RC Base Frame 1
201 196439 UBA/iPRO-RC Middle Frame 1
202 195324 Frame Transport Guide 1
203 195323 Pinch Roller Holder 4
204 195879 RC Pinch Roller 4
205 195935 Rear Transport Shaft 11 4
206 195899 Pinch Roller Spring 4
207 195966 UBA/iPRO-RC Rear Transport Assy. 1
208 196542 Double Note Detection Sensor LED 1
209 256324 Recycler CPU Board Assy. 1
210 006036 M3x4 Washer 6
211 113803 M3x8 Low Flat Head Screw (Nyloc) 4
212 149635 M3x4 Low Flat Head Screw (Nyloc) 4
213 003609 M3x6 W Washer 4
214 196553 End Detection Sensor Harness 1
215 196548 Lifter Motor Encoder Harness 1
216 196550 Sensor Harness 1
217 196551 Recycler Transport Motor Encoder Harness 1
218 216594 Recycler Board Power Harness 1
219 196562 Recycler Transport Motor Assy. (Upper) 1
220 196561 Recycler Transport Motor Assy. (Lower) 1
221 196539 Lifter Motor Assy. 1
222 196540 Flapper Open/Close Solenoid Assy. (Upper) 1
223 196541 Flapper Open/Close Solenoid Assy. (Lower) 1
224 196549 Flapper Open/Close Detection Harness 1
225 196552 Full Detection Sensor Harness 1
