Section 7 iPRO-RC™ Series Banknote Recycler Exploded Views and Parts Lists
iPRO-RC Frame Unit 4 Parts List
Table 7-5 iPRO-RC Frame Unit 4 Parts List
Ref No. EDP No. Description Qty Remark
400 196448 Frame Guide 3 1
401 196450 Sensor Cover 6
402 196446 Frame Guide 1 1
403 102984 Cash Box Holder B 1
404 052649 Box Lever Spring 1
405 196458 Box Pusher Holder 1
406 196471 Box Pusher Spring 1
407 196435 UBA/iPRO-RC Right Frame 1
408 196545 End Detection Sensor (Upper) LED 1
409 196545 End Detection Sensor (Lower) LED 1
410 196546 Full Detection Sensor (Upper) PT 1
411 196546 Full Detection Sensor (Lower) PT 1
412 196545 Lifter Home Detection Sensor LED 1
413 196546 Lifter Home Detection Sensor PT 1
414 128427 M3x5 Flat Head Screw (Nyloc) 6
