P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
Section 1 iPRO-RC™ Series Banknote Recycler General Information
Unit Dimensions
Entire Unit Outside Dimensions
Figure 1-6 illustrates the iPRO-RC™ Unit with the Bezel, Bezel Spacer and 400 Note Cash Box outside
dimensions.
Figure 1-7 illustrates the iPRO-RC™ Unit with the Bezel, Bezel Spacer, Lock Unit and 400 Note Cash
Box outside dimensions.
Figure 1-6 iPRO-RC Banknote Recycler Stan-
dard Unit with Bezel Outside Dimensions
Figure 1-6 iPRO-RC Banknote Recycler Standard Unit with Bezel Outside Dimensions
UBA/iPRO Bezel Unit
Bezel Spacer
MAX DEPTH7mm
NOTE: All dimension are in millimeters
MAX DEPTH7mm
Figure 1-7 iPRO-RC Banknote Recycler Stan-
dard Unit with Bezel, Lock Unit and Outside
Dimensions
Figure 1-7 iPRO-RC Banknote Recycler Standard Unit with Bezel, Lock Unit and Outside Dimensions
UBA/iPRO Bezel Unit
Bezel Spacer
MAX DEPTH7mm
NOTE: The Lock Unit is available
for installation on either the right
or left side of the Unit.
NOTE: All dimension are in millimeters
