P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
Section 7 iPRO-RC™ Series Banknote Recycler Exploded Views and Parts Lists
iPRO-RC Frame Unit 3 Parts List
Table 7-4 iPRO-RC Frame Unit 3 Parts List
Ref No. EDP No. Description Qty Remark
300 196451 RC Latch Case 1
301 196452 RC Latch Button 1
302 196472 Latch Button Spring 4
303 196453 RC Latch Left 1
304 196454 RC Latch Right 1
305 196437 Lift Motor Bracket 1
306 196475 Lift Up Shaft 1
307 007500 Bearing 2
308 196459 Lift Pitch Spacer 1
309 196473 Lift Up Gear 2
310 196474 Lift Motor Gear C 1
311 116208 Centering Home Position Sensor Board Assy. 1
312 196484 Reuse Clamp 3
313 196438 UBA/iPRO-RC Internal Frame 1
314 196442 RC Box Frame Ground Plate 1
315 201245 Polyacetal Washer (DURACON) 2
316 063250 2.6x6 Phillips, Self Tightening, Binding 2
317 113898 ø3x18 Parallel Pin (Hard) 2
318 133880 ø2x15 Parallel Pin (Hard) 2
319 196486 ø6.1xf8.0xt1.0 Poly Slider 1
320 003709 ø5 E-Ring 2
321 005683 M2x4 Washer 2
322 038938 ø2x10 Parallel Pin (Hard) 1
323 003707 ø3 E-Ring 1
324 010377 M2.6x5 W Washer (Small) 1
325 006036 M3x4 Washer 1
326 052564 2.6x6 Phillips, Self Tightening, Flat Head Screw 4
327 025195 M3x4 W Washer (Large) 4
To Next Page
