JCM iPRO-100-SH2-RC User Manual

P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
6-13
Performance Tests iPRO-RC™ Series Banknote Recycler Section 6
G ET A LL S ENSOR S TATE
Table 6-3 Get All Sensor State Configurations
Item Description
Status Text Field
I
ndication
Detected
Not
D
etected
Double (Transport)
Detect
s a Banknote’s presence on the Double Note Detection Sensor (Does
not detect double Banknotes)
ON OFF
Transport Sensor 1 Detects a Banknote’s presence on Transport Sensor 1 ON OFF
Transport Sensor 2 Detects a Banknote’s presence on Transport Sensor 2 ON OFF
RC1 Full
Detects that the RC1 Space is full
(Detects a “Full” condition while the Lifter is in the UP position)
ON OFF
RC2 Full
Detects that the RC2 Space is full
(Detects a “Full” condition while the Lifter is in the UP position)
ON OFF
RC1 End
Detects that the RC1 Space is Empty
(Detects an “End” condition while the Lifter is in the DOWN position)
ON OFF
RC2 End
Detects that the RC2 Space is Empty
(Detects an “End” condition while the Lifter is in the DOWN position)
ON OFF
Cash Box Sensor Detects that the Cash Box is seated ON OFF
Recycle Unit Sensor Detects that the Recycler Unit is seated ON OFF
Stacker Encoder Board
Detects the Pusher Plate’s Home Position of the Cash Box Pusher Plate
Home Sensor
ON OFF
Lifter Home Position Detects the Lifter’s Home Position of the Lifter Home Sensor ON OFF
RC1 Flapper Open
Detect the RC1 Space Flapper’s Open condition of the Flapper Open/Close
Sensor
OPEN CLOSE
RC2 Flapper Open
Detects the RC2 Space Flapper’s Open condition of the Flapper Open/Close
Sensor
OPEN CLOSE
DIP Switch1 Detects the DIP Switch 1 condition on the iPRO-RC™ Unit ON OFF
DIP Switch2 Detects the DIP Switch 2 condition on the iPRO-RC™ Unit ON OFF
DIP Switch3 Detects the DIP Switch 3 condition on the iPRO-RC™ Unit ON OFF
DIP Switch4 Detects the DIP Switch 4 condition on the iPRO-RC™ Unit ON OFF
DIP Switch5 Detects the DIP Switch 5 condition on the iPRO-RC™ Unit ON OFF
DIP Switch6 Detects the DIP Switch 6 condition on the iPRO-RC™ Unit ON OFF
DIP Switch7 Detects the DIP Switch 7 condition on the iPRO-RC™ Unit ON OFF
DIP Switch8 Detects the DIP Switch 8 condition on the iPRO-RC™ Unit ON OFF
When clicking on the “Get All Sensor State” Screen Button, each Sensor’s Status will appear in the “Sta-
tus
” Text Field. Table 6-3 lists all of the Sensor’s Functions and their Status Indications.
