P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
Section 6 iPRO-RC™ Series Banknote Recycler Performance Tests
( ) during the Performance Test, then
appears grayed-out once the Test is complete
( ). The iPRO-RC™ LED will appear
solid (non-flashing) Green when the Function has
performed normally. If an abnormal condition
occurs, the LED flashes Green. (Refer to the Table
A-4 on page A-3 in this manual for information on
LED Error Code Conditions.)
Table 6-2 lists the functions of each Performance
Test and the related LED configuration.
NOTE: The Test Status will not appear in the
Status Text Field unless the “Get All Sensor
State
” Screen Button is clicked! Only Motor
Speed will appear in the Status Fields when a
Motor Test is finished.
Table 6-2 Performance Test Configurations
Button Description
Status
Indication
Recycler Unit LED
Normal
(Stand-by/
Testing)
Abnormal
Transport Sensor Test
Detects a Banknote’s presence on the Double Note Detection
Sensor (Does not detect double Notes)
-
Green Lit
Green
Flash
*
Detect Banknote presence on Transport Sensor 1 -
Detect Banknote presence on Transport Sensor 2 -
Motor Test
RC1 Motor CW Speed: Checks the RC1 Space Transport
Motor’s Normal Rotation Speed
Speed
[mm/s]
RC1 Motor CCW Speed: Checks the RC1 Space Transport
Motor’s Reverse Rotation Speed
RC2 Motor CW Speed: Checks the RC2 Space Transport
Motor’s Normal Rotation Speed
RC2 Motor CCW Speed: Checks the RC2 Space Transport
Motor’s Reverse Rotation Speed
Flapper Test Checks the Flapper’s performance -
Green Lit
Green
Flash
*
Lifter UP Test Checks the Lifter’s Upward performance -
Lifter DOWN Test Checks the Lifter’s Downward performance -
*. Refer to Table A-4 in Appendix A of this Service Manual for further information regarding any Abnormal Green Flashes.
