P/N 960-000164R_Rev. 3 {EDP #213631} © 2018, JAPAN CASH MACHINE CO., LTD.
7-32
Section 7 iPRO-RC™ Series Banknote Recycler Exploded Views and Parts Lists
iPRO-RC Rear Transport Assembly 5 Parts List
Table 7-16 iPRO-RC Rear Transport Assembly 5 Parts List
Ref No. EDP No. Description Qty Remark
-- --
Rear Transport Main Frame 1 Assy. 4
150
0 005555 M2.6x6 W Washer (Small) 4
150
1 195959 Flapper Pusher Bracket Assy. 2
150
2 195921 Flapper Pusher Bracket Spring 2
150
3 195960 2.6x6 Phillips, Self Tightening, Washer Head 2
150
4 003707 ø3 E-Ring 2
150
5 196557 Flapper Open/Close Detection Board Assy. 2
150
6 063250 2.6x6 Phillips, Self Tightening, Binding 2
150
7 195933 Rear Transport Shaft 2
150
8 255582 Flapper Pusher Lever 2
150
9 003704 ø1.5 E-Ring 2
151
0 195962 Flapper Push Roller 4
1
511 003707 ø3 E-Ring 4
