Section 7 iPRO-RC™ Series Banknote Recycler Exploded Views and Parts Lists
iPRO-RC Frame Unit 5 Parts List
Table 7-6 iPRO-RC Frame Unit 5 Parts List
Ref No. EDP No. Description Qty Remark
500 196449 Frame Guide 4 1
501 196450 Sensor Cover 4
502 196447 Frame Guide 2 1
503 102983 Cash Box Holder A 1
504 052649 Box Lever Spring 1
505 196458 Box Pusher Holder 1
506 196471 Box Pusher Spring 1
507 196436 UBA/iPRO-RC Left Frame 1
508 196546 Full Detection Sensor (Upper) PT 1
509 196546 Full Detection Sensor (Lower) PT 1
510 196545 End Detection Sensor (Upper) LED 1
511 196545 End Detection Sensor (Lower) LED 1
512 128427 M3x5 Flat Head Screw (Nyloc) 6
To Next Page
