8
8 – 36
8.5
8. Press the
ENT
key to transmit the settings to the sensor.
• After transmission the display for indicating that transmission is completed appears.
• If transmission fails, the display for indicating that transmission error occurs appears.
In this case, check the sensor and cales.
Exit
9. Press the
SUB
MENU
key.
Initializing GPS ／ GPS status
INITIALIZE GPS / GPS STATUS
Press an item number key.
0. PREVIOUS MENU
1. POSITION N xx° xx. xxx'
Exxx° xx. xxx'
2. EXCLUSION SAT x x x x x x
3. GEODETIC xx
(xxxxxxxxxxx)
4. ANTENNA HEIGHT xxx M
5. FIX MODE 2D 3D
AUTO
6. DOP LEVEL UP to 5 UP to 10
UP to 20
7. POSN AVERAGE LONG MIDDLE
SHORT
8. SEND DATA
9.
GPS STATUS
GPS RCV TIME-––:––
N xx° xx. xxx' Exxx° xx. xxx'
xx ALT xxxxxM DOP xx
RCV SAT 31 15 28 22 ––––
FIX USE USE ––––––
AZIMUTH 354 202 306 126 ––––
ELEVATE 65 47 23 15 ––––
LEVEL 52 53 00 00 ––––
STATUS D D T S ––––
To close this menu, Press (SUB MENU) key.
To Next Page
