Range ／ range ring spacing → 3.3.3 Selecting Range Scales [RANGE] ／
→ 3.3.11 Displaying Fixed Range Ring [RR]
w
Bearing display → 3.3.7 Selecting Presentation Mode [PRESENTA-
TION MODE]
e
Relative motion (RM) ／ true motion (TM) display
→ 3.3.8 Selecting True Motion ／ Relative Motion
Display Modes [TM ／ RM] [TM RST]
r
Standby (STBY) ／ transmission (TX) display
→ 3.1.1 Turning Power on and Starting the System
t
Frequency band display
y
Mode selection display → 3.3.22 Selecting Display Mode [MAP]
u
Speed over ground
i
Course over ground
o
Own ship speed
!0
Own ship heading direction
!1
Stabilization mode display
!2
Target expansion display → 3.3.16 Enhancing Target
!3
Radar interference rejection → 3.2.9 Rejecting Radar Interference
!4
Set → 8.5.3.4 Setting Drift
!5
Drift → 8.5.3.4 Setting Drift
!6
Video processing → 3.3.20 Displaying Video Processing Screen
!7
Radar track (Trails) → 3.3.10 Displaying Other Ship's Trails [TRAILS]
!8
Auto FTC or Auto STC → 3.2.4 Suppressing Sea Clutter [SEA]
!9
Day ／ night display → 3.2.7 Selecting DAY ／ NIGHT Modes [DAY ／
NIGHT]
@0
Function name → 3.4 Using Function Key [FUNC]
@1
Cursor fixed display
@2
Pulse width → 3.3.4 Selecting Pulse Width [PL]
@3
Tuning indicator → 3.2.1 Tuning [TUNE]
@4
EBL 1 ／ 2 bearing
@5
VRM 1 ／ 2 range → 3.3.12 Displaying Variable Range Markers [VRM1
／ VRM2]
@6
Cursor bearing ／ range from own ship to cursor
@7
Cursor position LAT ／ LON
@8
Target data of ATA → 5.5.1 Types of Data Readouts to be Displayed
@9
Own ship position LAT ／ LON
#0
Own track color
#1
Mark ／ Line color
#2
Correcting chart posion
