Chapter 12: Qualification Reports
ValProbe RT User Manual 126
The following buttons on the bottom of the screen offer additional graphing options:
Zoom
By utilizing the zoom icons at the bottom of the screen or by using your fingers
you can zoom in or out or reset the zoom for enhanced analysis.
Y / X Scaling
Select the Manual Y – Scale button to manually adjust the Y axis scale. Use the X-Axis
Display button to select different options for displaying the X time axis.
Edit Sensors
Select Edit Sensors to choose the sensors to include in each Graph Report. Selections
made on the Graph Report screen are unique to the Graph Report and do not affect the
contents of the Setup, Qualification Detailed, or Qualification Summary Reports.
Options for choosing sensor colors and line thickness are available.
Important: Excluded sensors from any of the graph reports are not included in the
calculation graphs. To include sensors in calculation graphs excluded
previously for another graph view, select it again before switching to the
next calculation graph.
Edit Limit Labels
The Edit Limit Labels screen displays upper and lower limits on the graph. Available
sensor types depend on the sensor type for the graph.
To add limit lines to a graph, enter an upper and/or lower limit value or Avg(s) and label.
These display as horizontal lines at the selected measurement points. If desired, select
the line color, thickness, and style.
When finished, select Apply.
Generate Report
Select Generate Report to create a .pdf report of the graph. Enter a custom label and
select Apply. Use the option in the Summary Report to automatically include a
completed study graph in the Summary report.
