Chapter 2: Kaye ValProbe RT Hardware
ValProbe RT User Manual 14
Insulating Canister for High Temperatures
The Kaye ValProbe RT Insulating Canister (Part Number X2545) enables operation of
bendable Temperature Loggers from up to 400°C, by ensuring that the Logger base does not
exceed 140°C.
Figure 20: Insulating Canister (X2545)
IMPORTANT: Use the Insulating Canister in air applications only; do not submerge the
canister in liquid.
CAUTION! Use the Insulating Canister in non-hazardous locations only.
ATTENTION ! N'utilisez le boîtier isolant que dans des endroits non dangereux.
Inserting a Logger into an Insulating Canister
For dual and single bendable Loggers only, unscrew the protective housing cap from the
Logger.
Remove the cap by pressing down on the cap and turning it counterclockwise until the clips are
free from the tabs.
Place the PEEK cylinder over the bendable Temperature Logger probe and slide it to the
base of the Logger.
Place the Logger and PEEK cylinder into the canister.
Insert the probe through the Insulating Canister cap center hole and slide the cap to the
cylinder base. Line up the clips with the tabs on the cylinder base. Press down on the cap
and turn clockwise so that the clips are secured onto the tabs.
Figure 21: Inserting a Logger into an Insulating Canister
